1500
kg
Lifting Capacity
3000
mm
Lifting Height
24/100
V/Ah
Battery Capacity
0.75 DC
kW
Travel Motor
2.2 DC
kW
Lifting Motor
6
Hours
Continuous Operation
| H4 |
Lift Open Height |
3500 mm |
| H3 |
Lifting Height |
3000 mm |
| H2 |
Free Lifting |
100 mm |
| H1 |
Lift Closed Height |
2010 mm |
| I |
Fork Length |
1115 mm |
| Q |
Lifting Capacity |
1500 kg |
| S |
Fork Thickness |
60 mm |
| H14 |
Total Height with Arm |
870/1200 mm |
| H13 |
Minimum Fork Height |
85 mm |
| H12 |
Wheel Body Distance |
162 mm |
| H11 |
Body Height |
800 mm |
| Y |
Axle Distance |
1384 mm |
| C |
Load Centre |
600 mm |
| % |
Loaded/Unloaded Maximum Slope |
3/10 |
|
B1 |
Width dimension |
800 mm |
|
B10 |
Drive Wheel and Balance Wheel Axle |
526 mm |
|
B11 |
Distance Between Forks |
250 mm |
|
B5 |
Total Fork Width |
570 mm |
|
AST |
Total Length |
1830 mm |
|
E |
Fork Width |
160 mm |
|
X |
Distance Between Axle and Body |
780 mm |
|
N |
Weight |
496 kg |
PRODUCT
FEATURES
- High Performance Pump and Cylinder with DC Motor
- American Curtis Control Card
- Fast and Slow Motion Mode
- Last Height Protection Switch
- American Curtis Control Card
- Fast and Slow Motion Mode
- Last Height Protection Switch
1500 KG CARRYING CAPACITY
MAXIMUM HEIGHT 600 KG
3000 MM LIFTING HEIGHT
MAXIMUM TRANSPORT HEIGHT 250 MM
AMERICAN CURTIS CONTROL CARD
MAINTENANCE FREE GEL BATTERY
DC MOTOR
POSSIBILITY TO WORK ON SHELVES IN NARROW SPACE
LIMIT LIQUID AT FINAL HEIGHT
C TYPE ST52 STEEL MAST
SLOW WALKING MODE
WALK-BACK SAFETY TO PROTECT THE OPERATOR
SUITABLE FOR EURO PALLET
