1600
kg
Lifting Capacity
5500
mm
Lifting Height
24/280
V/Ah
Battery Capacity
1.5 AC
kW
Travel Motor
3.0 DC
kW
Lifting Motor
6
Hours
Continuous Operation
|
H4 |
Lift Open Height |
6000 mm |
|
H3 |
Lifting Height |
5500 mm |
|
H2 |
Free Lifting |
100 mm |
|
H1 |
Lift Closed Height |
2440 |
|
I1 |
Overall Length |
1984 mm |
|
I |
Fork Length |
1115 mm |
|
Q |
Lifting Capacity |
1600 kg |
|
X |
Distance between Axle and Body |
783 mm |
|
S |
Fork Thickness |
60 mm |
|
M |
Minimum Ground Clearance |
|
|
H14 |
Total Height with Arm |
|
|
H13 |
Minimum Fork Height |
|
|
I1 |
Overall Length |
|
|
Y |
Axle Distance |
|
|
C |
Load Centre |
|
|
% |
Loaded/Unloaded Maximum Slope |
|
B1 |
Width Dimension |
|
|
B10 |
Drive Wheel and Balance Wheel Axle |
|
|
B11 |
Distance Between Forks |
|
|
B5 |
Fork Width |
|
|
AST |
Aisle Width 2450 mm for 1000x1200 Size Pallet |
2450 mm |
|
AST |
Aisle Width for AST 800x1200 Size Pallet 2398 mm |
2398 mm |
|
WA |
Minimum Rotation Angle ı |
1620 mm |
|
E |
Fork Dimensions |
160 mm |
|
X |
Distance between Axle and Body |
780 mm |
|
N |
Weight |
1510 mm |
PRODUCT
FEATURES
-Wide and Balanced Body
-AC Walking Motor
-High Capacity Traction Battery
-Impact Resistant Professional Chassis
-Heavy Duty Fork Structure
-Operator Platform
-AC Walking Motor
-High Capacity Traction Battery
-Impact Resistant Professional Chassis
-Heavy Duty Fork Structure
-Operator Platform
1600 KG CARRYING CAPACITY
MAXIMUM HEIGHT 800 KG
4600 MM LIFTING HEIGHT
AMERICAN CURTIX CONTROL CARD
TRACTION BATTERY
UNMAINTAINED AC MOTOR
POSSIBILITY TO WORK ON SHELVES IN NARROW SPACE
H TYPE TENSILE STEEL MAST
LIMIT LIQUID AT FINAL HEIGHT
SLOW WALKING MODE
WALK-BACK SAFETY TO PROTECT THE OPERATOR
SUITABLE FOR EURO PALLET
