1500
kg
Lifting Capacity
4600
mm
Lifting Height
24/210
V/Ah
Battery Capacity
1.50
kW
Travel Motor
3
kW
Lifting Motor
6
Hours
Continuous Operation
| H4 |
Lift Open Height |
5024 mm |
|
H3 |
Lifting Height |
4600 mm |
|
H2 |
Free Lifting |
1660 mm |
|
H1 |
Lift Closed Height |
2020 mm |
|
I |
Fork Length |
1115 mm |
|
Q |
Lifting Capacity |
1500 kg |
|
X |
Distance between Axle and Body |
672 mm |
|
H14 |
Total Height with Arm |
870/1.200 mm |
|
H13 |
Minimum Fork Height |
86 mm |
|
H12 |
Wheel Body Distance |
162 mm |
|
H11 |
Body Height |
800 mm |
|
Y |
Axle Distance |
1384 mm |
|
C |
Load Centre |
600 mm |
|
% |
Loaded/Unloaded Maximum Slope |
4/10 |
|
B1 |
Overall Length |
2060 mm |
|
B10 |
Drive Wheel and Balance Wheel Axle |
526 mm |
|
B11 |
Load Wheel Axle |
390/515 mm |
|
B5 |
Fork Width |
570/695 mm |
|
I |
Total Length |
2022 |
|
AST |
Aisle Width for 1000x1200 Size Pallet |
2435 mm |
|
AST |
Aisle Width for 800x1200 Size Pallet |
2412 mm |
|
WA |
Minimum Rotation Angle |
1150 mm |
|
E |
Fork Dimensions |
160 mm |
|
X |
Distance Between Axle and Body |
642 mm |
|
N |
Weight |
1206 kg |
PRODUCT
FEATURES
- German ZF Transmission
- AC Walking Motor
- 1600mm Freelift Lifting
- High Capacity Traction Battery
- Impact Resistant Professional Chassis
- AC Walking Motor
- 1600mm Freelift Lifting
- High Capacity Traction Battery
- Impact Resistant Professional Chassis
1500 KG CARRYING CAPACITY
MAXIMUM HEIGHT 800 KG
4600 MM LIFTING HEIGHT
MAXIMUM TRANSPORT HEIGHT 250 MM
AMERICAN CURTIS CONTROL CARD
UNMAINTAINED AC MOTOR
TRACTION BATTERY
POSSIBILITY TO WORK ON SHELVES IN NARROW SPACE
LIMIT LIQUID AT FINAL HEIGHT
H TYPE TENSILE STEEL MAST
SLOW WALKING MODE
WALK-BACK SAFETY TO PROTECT THE OPERATOR
EURO PALLET SUITABLE
